1.Principle of bean dregs dryer
    The Bean dregs dryer consists of heat supply source, feeding machine, revolving cylinder, discharging machine, induced-draft fan, tripper, and power distribution cabinet;
    After The Bean dregs enter the dryer machine, the wet Bean dregs distributes in the dryer equably and contacts the hot air fully when flipped by the lifting plate in the drum, this will quicken the heat transfer and mass transfer.During the drying process, with action of the inclined lifting plate and heat medium, the dried Bean dregs is discharged from the star-shape discharge valve in another side of the dryer.
2.Main Characteristics
1.The revolving drum is characterized by a high degree of mechanization, high production capacity, and continuous running;

2.Excellent and simple structure, smooth running of the material in cylinder, convenient operation;

3. Less breakdown, low maintenance cost and low power loss

4.Wide application and even drying effect


Technical Parameter

Model DLZG1610 DLZG2010/3 DLZG2510/3 DLZG2910/3 DLZG3210/3 DLZG3510/3
Capacity (t/h) 2.25 4.5 6.75 9.0 11.25 13.5
Output(t/h) 0.5 1 1.5 2 2.5 3
Initial Moisture(%) 80-85%
Final Moisture(%) ≤12%
Total Power (kw) 125 185 225 280 335 380
Total Weight(kg) 50000 60000 70000 80000 90000 100000
Plant Area (m²) 40m*12m 42m*15m 45m*15m 48m*15m 50m*15m 50m*15m
